HDMI 1x8 Splitter & Cat6/6a/7 Extender with 8 Receivers - PoC/IR/EDID

1.059,00 € *1

zzgl. Umsatzsteuer zzgl. Versandkosten

Nicht am Lager! Ware wird nachbestellt. Zulieferung je nach Verfügbarkeit beim Hersteller ca. 5-30 Werktage.

  • OM-HDMICAT1X8
  • OMX-HDMICAT1X8
  • 4,00 kg
Ocean Matrix OMX-HDMICAT1X8 HDMI 18Gbps 4K@60Hz 1x8 Splitter & Cat6/6a/7 Extender with 8... mehr

Ocean Matrix OMX-HDMICAT1X8 HDMI 18Gbps 4K@60Hz 1x8 Splitter & Cat6/6a/7 Extender with 8 Receivers - PoC/IR/EDID

Distribute and extend HDMI signals in brilliant 4K quality to 8 displays at a range over 100 feet with the Ocean Matrix HDMICAT1X8. This system is perfect for digital signage applications in sports bars, restaurants and businesses as well as trade show booths and similar live event spaces. The HDMICAT1X8 supports Power Over Copper to simplify installations at displays or projectors and the system also offers built-in EDID management to ensure your signals are always on.

The Ocean Matrix HDMICAT1X8 supports HDMI 2.0 4K2K@50/60Hz 4:4:4 signals. The base unit of the system has 8 outputs designed for signal distribution over CAT6/6A/7 infrastructures and receiver units can be up to 115 feet away. The system also supports IR control.

Features:

  • Extends 4K2K@50/60Hz up to 35m, 4K2K@30Hz up to 50m, 1080p up to 60m over CAT/6/6a/7 cable
  • Includes 8 Receivers
  • Supports 3D, HDR, HDR10+, HLG and Dolby vision
  • Advanced EDID Management
  • One-Way PoC from Tx to Rx
  • One-Way IR Control
  • HDMI Loop Out
  • 12V/2.5A DC Locking Power Adapter
  • Metal Enclosure

Specifications:

  • HDMI 2.0, HDCP 2.2, and DVI 1.0 Compliant
  • Audio Pass-Through up to 7.1CH HD Audio
  • Supports 3D, HDR, HDR10+, HLG, and Dolby Vision
  • Supports Digital and Analog Audio De-embedded Outputs
  • Video Bandwidth: 18Gbps
  • Power Consumption: 25.44W
  • Power Input: 100-240V AC 50/60Hz
  • Power Output: 12/2.5A DC
  • Dimensions (WxDxH): TX 11.8 x 3.9 x 1.1 inch / RX 3.5 x 2.4 x 0.7 inch
  • Weight: TX 1.81 lb / RX 0.34 lb

Item Includes:

  • (8) CAT Receivers
  • (8) 20K-60KHz IR Receiver Cables (1.5m)
  • (1) IR Blaster (1.5m)
  • (1) 12V/2.5A DC Locking Power Adapter



Funktion: HDMI Extender
Technologie: HDbase-T
Bauform: Mini Converter
Inputs: HDMI
Outputs: HDMI
Anschluß: HDMI-A
Eigenschaften: "HDMI 1x8 Splitter & Cat6/6a/7 Extender with 8 Receivers - PoC/IR/EDID"
Funktion: HDMI Extender
Technologie: HDbase-T
Bauform: Mini Converter
Inputs: HDMI
Outputs: HDMI
Anschluß: HDMI-A

OCEAN MATRIX ist eine Division der Tower Products Incorporated, New Jersey, USA, und spezialisiert auf die Entwicklung und Herstellung von praktischen Hilfsmitteln für die professionelle und semi-professionelle AV-Technik.

Zum umfangreichen Lieferprogramm gehören Trenntrafos, Kleingeräte zur Übertragung und Signalanpassung.

vuetec.tv UG importiert die OCEAN MATRIX Produkte exklusiv und vertreibt sie im europäischen Raum.
