:WAVE - Timecode Generator
:WAVE - Timecode Generator
:WAVE - Timecode Generator
:WAVE - Timecode Generator

:WAVE - Timecode Generator

778,90 € *1

zzgl. Umsatzsteuer zzgl. Versandkosten

lagernd. Lieferzeit je nach Versandart 1-3 Werktage

  • TS-WAVE
  • :wave
:WAVE Designed to be the perfect companion for your sound mixer, the :wave offers advanced... mehr

:WAVE

Designed to be the perfect companion for your sound mixer, the :wave offers advanced capability to sync, log, control and report.

Features

  • Highly accurate timecode, genlock & word clock
  • BLINK enabled master or slave
  • Zero drift between units using long range B:LINK RF
  • Simultaneous RF, Wi-Fi & DATA port connectivity
  • Wireless view, monitor & control using the B:LINK Hub

Optimised for the sound department
First and foremost, the :wave is a highly accurate timecode, genlock and word clock generator with an integrated RF transceiver. But it’s the advanced features enabled by integrated simultaneous Wi-Fi and the power of the BLINK protocol that really make the :wave stand out.
Once added to your set-up, you can use the :wave to experience the full benefits of our BLINK protocol. Connect to the BLINK Hub (coming soon) to remotely view, monitor and control any of our B:LINK enabled devices from your smartphone, tablet or computer.

Sync, log, control, report
A new firmware upgrade for the :wave (download here) offers tailormade functionality to support Sound Devices 6-Series mixer/recorders, giving audio department users the ability to sync and share metadata and timecode via a bespoke Timecode Systems Sync lead from the :wave’s data port to the USB port on a Sound Devices 6-Series mixer/recorder.
This not only ensures all recorded sound files contain the same accurate timecode as the cameras, but also allows full exchange of metadata and opens the future capability to remotely monitor status and control, and wirelessly enable the mixer/recorder in the from the BLINK Hub.
For even more advanced logging and reporting, a seamless exchange of data between Sound Devices’ 6-Series mixer/recorders, the :wave and the MovieSlate® 8 iOS app, allows users to connect to effortlessly generate stunning sound reports.

User friendly features
BLINK RF: Synchronisation between units is via BLINK RF – a wireless long-range sync, control and metadata exchange protocol operating in the uncongested range of 865MHz to 923MHz. This ensures complete reliability, wherever you are, and zero drift between units even on a long and complicated shoot day.
Compact & robust: The :wave is small (94mm x 67mm x 23mm), has a solid aluminium casing and features a high resolution blue OLED display, flexible mounting methods and multiple powering options (5V micro USB connector, LEMO2 9-36V DC plus internal back up battery).
Battery back-up: The large capacity Li-Polymer internal battery is constantly charged from any power input and is designed to run the unit for a minimum of 8 hours with RF and Wi-Fi switched on, much longer without Wi-Fi enabled, making it perfect for audio and camera battery swaps or location moves.

Funktion: Timecode Generator + Transceiver
Bauform: Mini Converter
Antennen: 1x extern
Inputs: Daten, Video Sync (BB)
Outputs: Timecode
Power: 5 V DC, 9 ~ 36 V DC
Standards: 60 / 50 / 30 / 25 / 24 Hz
Steuerung: App , App :BLINK, lokal
Technical Specs: Timecode generator accuracy: 0.2 ppm TCXO reference oscillator (less... Technische Daten

Technical Specs:

Timecode generator accuracy: 0.2 ppm TCXO reference oscillator (less than one half frame drift a day)
External Power 5V micro USB connector, LEMO2 9-36V DC
Internal Power Backup Li Polymer rechargeable battery with 8 hours min operation (WiFi and RF switched on)
T/C input five pin LEMO (pin 2 sig, pin 1 gnd). 0.1 to 5V pp
T/C outputs Three Buffered outputs on BNC, LEMO 5 and separate LEMO 9 connectors. Selectable MIC or LINE output level on LEMO5
Supported FPS modes 23.98, 24, 25, 29.97, 30, 29.97DF, 30DF
Output sync modes PAL, NTSC, 720p, 720p double frame, 1080i, 1080p, 1080p double frame, Word Clock 44.1, 48.2, 48, 96, 192 KHz
Output Video Sync 1V pp / 75 ohm or 1V pp /37.5ohm for ‘High Level Genlock’ mode (3D camera rigs)
Display Blue OLED 128 x 32 pixel resolution
Frequency

865MHz-923MHz, Worldwide ISM bands. 2.4GHz 802.11g Wi-Fi

Wired connectivity USB, UART, RS232, RS422, LANC
Dimensions 94 x 67 x 23 mm
Weight 220 g
Eigenschaften: ":WAVE - Timecode Generator"
Funktion: Timecode Generator + Transceiver
Bauform: Mini Converter
Antennen: 1x extern
Inputs: Daten, Video Sync (BB)
Outputs: Timecode
Power: 5 V DC, 9 ~ 36 V DC
Standards: 60 / 50 / 30 / 25 / 24 Hz
Steuerung: App , App :BLINK, lokal

Timecode Systems ist ein britscher Hersteller von Geräten und Systemen zur synchronen Verkopplung von verschiedenen Audio-, Video- und Datengeräten für die Bereiche Broadcast, Produktion, Film, Live-Performance und mehr durch standardisierten Timecode. Er ist spezialisiert auf das Design und die Herstellung von praxisorientierten Produkten, unter Verwendung modernster Technologie mit höchster Zuverlässigkeit. Zu den Highlights gehören drahtlose Generatoren und Synchronizer.

vuetec.tv UG fungiert als exklusiver Vertrieb für den deutschsprachigen Raum.
